Angled Industrial Meter Regulator - 1.1/4" x 1.1/4”

Name: Angled Industrial Meter Regulator - 1.1/4" x 1.1/4”
Brand: Unbranded
SKU: 6264
Price: 155.96 GBP
Availability: InStock

Angled pattern regulator designed for use with U and G series gas meters. Approved to BS EN 88/+A1 (Class A. Group 2) and meets the essential requirements of the European Gas Appliance Directive (GAD 2009/142/EC).

Maximum inlet pressure: 200 mbar.

Operating temperature range: -20 to 70°C.

The regulators are supplied fitted with a spring to give an outlet pressure of 12 to 25 mbar, set at 21 mbar. A different outlet pressure range may be obtained by fitting an alternative spring.

Supplied complete with a brass outlet adaptor incorporating the BS 746 meter connection thread. If the BS 746 adaptor is to be used, a washer (not supplied) is needed; (P/N 8783).

Application: 1.1/4" U16, G10.

For Natural Gas and LPG.

Industrial/Angled Springs

Springs are listed in the Product Options below. NOT fitted to a regulator.

P/N	Outlet pressure ranges
10400	5-15 mbar
15537	22-35 mbar
10192	35-70 mbar
13638	70-80 mbar

Product Specification

Standards	BS EN 88/+A1
Connection	1.1/4" BS 746 F
Inlet Pressure	Max: 200 mbar
Operating Temperature	-20 to 70°C
Pattern	Angled
Size	1.1/4"
Suitable Application	For use with U and G series gas meters
Type	Regulator
