BritTherm™ SL25 25-80/180 Commercial Central Heating Circulator Pump

£196.56 £163.80
£196.56 £163.80
More product options available

Part Number: 24993

Manufacturer's Part Number: SL25

BritTherm™ SL25 25-80/180 Commercial Central Heating Circulator Pump

The BritTherm™ SL25 25-80/180 Commercial Central Heating Circulator Pump is a highly effective, reliable 3-speed fixed manual heating circulator designed for seamless integration. Featuring a standard 1.1/2" threaded connection and a convenient port-to-port distance of 180mm, this pump delivers optimum performance.

With a maximum head of 8 meters making it perfect for replacing existing circulators in large domestic and light commercial heating systems, ensuring efficient and consistent heating throughout your space. Perfect for central heating system pumps, it boasts a maintenance-free design for the entire service life, guaranteeing high reliability.

Easily control the pump with three constant speeds, adjustable via a mechanical switch for added convenience. With a IP44 rating it ensures durability and protection against dust and moisture with a robust cast iron black body.

For added convenience, this circulator operates on a standard 230 V AC, 50 Hz power supply. Its manual speed setting provides you with three-speed options, allowing you to tailor its performance to your specific needs. The circulator can handle a temperature range from 2 to 110°C, ensuring versatility in various applications.

Backed by a 3-year BritTherm™ guarantee, the SL25 offers peace of mind and long-lasting performance.

Compatible motorised valves and pump valves available.

Benefits

  • Three fixed speed manual control
  • 180mm port-to-port distance
  • 1.1/2" threaded connection
  • 8-metre maximum head
  • 10-bar max operating pressure
  • 2 to 110°C temperature range
  • IP44 rating for durability and moisture protection
  • Robust cast iron body
  • 3-year BritTherm™ guarantee

Product Specification

Brand BritTherm™
Connection 1.1/2" BSP M
Energy Efficiency Index ≤0.23
Liquid Temp. Range 2°C to 110°C
Max. Head 8 m
Max. Operating Pressure 10 bar
Port To Port 180 mm
Power Supply 230 V, 50 Hz
Size 1.1/2"
Type Circulating Pump
Weight 4.2 kg
