Part Number: 12648
Butane Pigtail Assembly 20" ST Butane Nut x W20
S/T Butane Nut x W20 Nut and Tail.
High pressure hose to (and marked) BS 3212 Type 2 or BS EN 16436-1 Class 3, assembled to BS 3212. A self adhesive advisory label is attached to every hose. Red labels for those fitted with full non-return/excess flow valve fittings and a yellow label for other assemblies. S/T indicates straight through and N/R indicates a non-return/excess flow valve. For Butane only.
Product Specification
Application | Butane |
Braiding | Unbraided |
Standards | BS 3212:1991 Type 2 |
Burst Pressure | 69 bar |
Colour | Black |
Connection | S/T Butane Nut x W20 Nut + Tail |
Gas Type | Butane |
Inside Diameter | 6.3 mm |
Length | 20" |
N/R or S/T | S/T |
Operating Pressure | Working pressure: 20 bar |
Outside Diameter | 15.5 mm |
Suitable Application | Butane |
Type | Pigtail Assembly |
