Clesse Propane Low Pressure Regulator - 10.5 kg/hr

£120.64 £100.53
£120.64 £100.53
More product options available

Part Number: 21474

Manufacturer's Part Number: 006827AA

Clesse Propane Low Pressure Regulator - 10.5 kg/hr

Clesse UPSO/OPSO 2nd stage regulator. Manufactured in the EU to BS EN 16129.
Capacity: 10.5 kg (493,500 Btu) per hour.
Operating pressure: 37 mbar.
Inlet pressure : 0.45 to 2 bar.
OPSO: 100 mbar.
UPSO : 27 to 30 mbar.
Relief valve: 75 mbar.
Inlet: 1/2" BSP TF.
Outlet: 3/4" BSP TF.

Product Specification

Ambient Temperature -20 to 50°C
Brand Clesse
Standards BS EN 16129:2013
Capacity 10.5 kg/h
Connection BSP
Flow Rate 10.5 kg/h
Inlet 1/2" BSP TF
Inlet Pressure 0.45 - 2 bar
Operating Pressure 37 mbar
OPSO Yes
Outlet Connection 3/4" BSP TF
Pressure Release Valve No
Pressure Test Point Yes
Size 1/2" BSP TF x 3/4" BSP TF
Stage Second
Sub Brand Clesse
Suitable Application Propane Low Pressure
Type Second Stage Low Pressure
UPSO Yes
Vent Position Giro
