Part Number: 23906

Manufacturer's Part Number: RF562DR

Drayton LP20RF Clip-in and Digistat+RF

The LP20RF wireless Clip-in module is a 7 day, two channel programmer with built-in wireless receiver and pre-wired PCB connector that controls 3 ON/OFF times per day for heating and hot water pre-heat function.
The Digistat+RF wireless battery powered room thermostat controls the heating temperature.
ErP rating Class 4.
For Worcester Bosch boilers Greenstar CDi, Greenstar Si, Greenstar i Junior models

Product Specification

Back Light	Yes
Brand	Drayton
Display	LCD
ErP Rating	Class 4
IP Rating	LP20RF - IP24, Digistat - IP30
Kit Contents	LP20RF Clip-in module and Digistat+RF
Mounting	For Worcester Bosch boilers except Greenstar 25i and 30i models.
No. of Channels	Two
Receiver Dimensions	120 x 134 x 15 mm
Receiver Power Supply	24 V D.C. less than 65mA
Summer/Winter Clock Change	Yes
Temperature Changes/Day	3
Temperature Range	5 to 30° C
Thermostat Dimensions	89 x 86 x 39 mm
Thermostat Power Supply	2 x AA Batteries
Type	Combi Boiler Controls
Wireless	1
7 or 5/2 Day	7 Day
