Part Number: 22352

G25P Diaphragm Gas Meter - 40m³/hr

40 m³/hr Diaphragm gas meter manufactured by BS EN ISO 9001:2008 companies in Europe, certified under the European certification regime, and sealed.
Check that this meter has the inlet/outlet dimension ‘A’ and thread size which meet your requirements because these may differ from the traditional ‘UK’ meter dimensions.
Meter reads in cubic metres and is supplied complete with pulse plug and lead.
Suffix P indicates a meter with a pulse facility, this need not be used.
Not fitted with a test point.


No claim in respect of damage, internal or external, to a gas meter will be accepted unless such damage is notified in writing by the end of the working day following our customer’s receipt of the meter. We suggest that the internal mechanism is checked by passing air through the meter and noting that it registers.

Product Specification

Standards BS EN ISO 9001:2008
Capacity 40 M³/h
Connection 2" BSP TM
Dimensions A = 335 Mm
B = 457 Mm
C = 141 Mm
D = 313 Mm
E = 361 Mm
Display Mechanical
Material Steel
Max. Capacity 40 M³/hr At 0.5 Mbar Pressure Loss
Max. Operating Pressure 500 Mbar
Meter Code G45P
Meter Connection Size 2" BSP TM
Meter Type Diaphragm
Pulse Rate 0.1 M³/pulse
Suitable Application Natural Gas & LPG
Test Point No
Type Commercial Meter
