Gas Meter Washer to BS 746 Table 8 - 3/4"

Name: Gas Meter Washer to BS 746 Table 8 - 3/4"
Brand: Unbranded
SKU: 8720
Price: 0.15 GBP
Availability: InStock

Black rubber type washer to BS 746 Table 8. for meter unions.

For meter adaptors and caps use washer 8259.

BS 746 Conversion

BES Ltd Gas Meter Union – BS 746 Thread Conversion Chart

BS 746 is the specification that applies specifically to Gas Meter Installations. The size name refers to the internal bore size of the meter unions and the ECV (main gas cock), not the thread diameter. To ensure you order the correct fittings, please measure the thread diameter of the male thread on your meter or ECV in millimetres, and then use the chart below to identify the BS 746 size.

BSP 746 Name	Actual Thread Size in mm	Nut Size (Flat to Flat) in mm
3/4"	29 mm	35 mm
1"	37 mm	42 mm
1 1/4"	44 mm	53 mm
1 1/2"	57 mm	66 mm
2"	76 mm	80 mm

Product Specification

Standards	BS 746 Table 8
Material	Black Rubber
Size	3/4"
Suitable Application	For use with P/Ns 0244, 0260, 6283, 6284 and 3202. For Natural Gas and LPG.
Type	Washer
