Part Number: 18800

GS Pro-Fi 3 Fuel Oil De-aerator with Filter

The GS Pro-Fi 3 combines a fuel filter, de-aeration device with filter and shut off valve in one module. Suitable for internal installations as the device does not vent to atmosphere.
Meets OFTEC OPS 23 (GB) : 11-2007 requirements.
Specification :
Max. oil throughput in pump cycle : 80 l/h light oil.
Max. oil throughput at burner jet : 120 l/h light oil.
Max. pressure : 16 bar.
Max. operating temperature : 80°C.
Max. ambient temperature : 80°C.
Max. de-aeration capacity : 5 l/h air.
Pipe connections : 3/8" BSP.

Product Specification

Ambient Temperature Max: 80°C
Standards OFTEC OPS 23 (GB) : 11-2007
Connection 3/8" BSP
Max. Operating Pressure 16 Bar
Max. Operating Temperature 80°C
Model Name GS Pro - Fi3
Size 3/8"
Suitable Application Internal Installations
Type De-Aerator
