Industrial Regulator - 1.1/2" F x F

£121.40 £101.17
£121.40 £101.17
More product options available

Part Number: 8192

Industrial Regulator - 1.1/2" F x F

Service and appliance regulator suitable for a wide range of domestic, commercial and industrial applications. May be installed in horizontal or vertical pipework.

Sizes up to and including 2" are approved to BS EN 88-1:2007 (Class A Group 2) and meet the essential requirements of the European Gas Appliance Directive (GAD 2009/142/EC).

Operating temperature range: -20 to 70°C.

Maximum inlet pressure: 75 mbar.

The regulators are supplied fitted with a spring to give an outlet pressure of 17.5-25 mbar (7"-10" wg), set at 21 mbar. A different outlet pressure range may be obtained by fitting an alternative spring.

Thread: 1.1/2" BSP female to BS EN 10226-1:2004.

For Natural Gas and LPG.

Industrial/Angled Springs

Springs are listed in the Product Options below. NOT fitted to a regulator.
P/N Outlet pressure ranges
10400 5-15 mbar
15537 22-35 mbar
10192 35-70 mbar
13638 70-80 mbar

Product Specification

Standards BS EN 88-1:2007. GAD 2009/142/EC
Connection 1.1/2" BSP F
Inlet Pressure Max: 75 mbar
Operating Temperature -20°C to 70°C
Outlet Pressure 17.5 to 25 mbar
Pattern Straight
Size 1.1/2"
Suitable Application Service and appliance regulator for a wide range of domestic, commercial & industrial applications
Type Regulator
