Part Number: 26924
Manufacturer's Part Number: HPBV11FS
Inta Full Bore Ball Valve - 1" BSP Swivel x 1" BSP Swivel with Ext. Lever
Full bore ball valve with extended lever to allow for insulation, minimising heat loss. Manufactured from solid brass and designed to be fitted directly onto the heat pump to avoid the need to drain down when performing maintenance.
Pressure rating of PN 25.
Pressure rating of PN 25.
Product Specification
| Brand | Inta |
| Standards | BSP to BS EN ISO 228 |
| Application | Heat Pumps |
| Connection | BSP F Swivel x BSP F Swivel |
| Finish | Plated |
| Full Bore | Yes |
| Handle | Lever |
| Handle Colour | Black |
| Lockable | No |
| Material | Brass |
| Max. Operating Pressure | 25 bar |
| Operating Temperature | -10 to 90°C |
| Size | 1" |
| Type | Full Bore Ball Valve |
