Part Number: 23995
Manufacturer's Part Number: MW30HP
Pulsed Hot Water Meter - 1.1/4"
30 mm nominal bore, 1.1/4" BSP TM thread.
Pulsed water meter for use in the monitoring of consumption usually linked with an energy monitoring system. Cast copper alloy meter body with multi jet and vane wheel operation. Fitted with inductive interface and electronic pulse emitter module (interface is compatible with Mbus modules) with 1.5 m lead.
Approved according to MID standards up to R100-H and R50-VH.
Pulsed water meter for use in the monitoring of consumption usually linked with an energy monitoring system. Cast copper alloy meter body with multi jet and vane wheel operation. Fitted with inductive interface and electronic pulse emitter module (interface is compatible with Mbus modules) with 1.5 m lead.
Approved according to MID standards up to R100-H and R50-VH.
Product Specification
Application | Monitoring hot water consumption. |
Approved by | WRAS |
Bore | 30 mm |
Connection | BSP TM |
Hot Water Meter Max Temp | 90° C |
Material | Copper Alloy |
Max. M3/H | 10 |
Max. Operating Pressure | 16 bar |
Measurement | 1 pulse per 10 litres |
Nominal Bore | 30 mm |
Pulsed Facility | Yes |
Size | 1.1/4" |
Type | Hot Water Meter |
