Part Number: 6898
Solenoid Gas Safety Shut Off Valve - 1/4"
12 V DC, BSP F x F, normally closed without manual reset.
1/4" BSP for LPG or Natural Gas. Normally closed valve which is held open by electric current. Power interruption closes the valve; power supply opens the valve. It can be electrically connected to an alarm system and/or a knock-off switch. May be mounted in any orientation, provided direction of flow agrees with arrow on body.
Product Specification
Ambient Temperature | 60°C |
Connection | BSP F x F |
Differential Pressure | 0 to 0.1 bar (100 mbar, 1.47 p.s.i.) |
For Use With | LPG or Natural Gas |
IP Rating | IP 65 |
Power | 12 V DC |
Pressure Rating | 0 to 0.1 bar |
Size | 1/4" |
Suitable Application | Gas Safety Shut Off Valve, can be electrically connected to an alarm system and/or a knock-off switch. |
Type | Solenoid Valve |
Voltage | 12 V |
