Steel Convoluted Hose 4ft x 3/4" Unbraided Male Adaptor

£38.90 £32.42
£38.90 £32.42
More product options available

Part Number: 6072

Steel Convoluted Hose 4ft x 3/4" Unbraided Male Adaptor

Flexible metallic hose assemblies to BS EN ISO 10380:2003. The flexible hose is stainless steel, the end fittings are stainless steel or (carbon) steel. These hoses are suitable for Natural gas, LPG, water (but not potable water) and steam. Assembly temperature range : -20 to 400°C. The polyolefin cover is white or yellow according to stock.

For quick disconnect automatic shut-off couplings for use with water Click Here.

NOTE : With bayonet hoses the pressure limitations are fixed by the bayonet plug and socket which is identical to that used on domestic cooker installations and is tested to 50 mbar at a maximum temperature of 95°C.

Product Specification

Bore 3/4"
Braiding Unbraided
Standards BS EN ISO 10380:2003
Colour White/Yellow
Connection BSP TM X F Swivel
Finish Polyolefin
Fittings TM X F Swivel + M X M Adaptor
Length 4 Ft
Material Stainless Steel
Max. Operating Pressure Working: 3.6 Bar
Size 3/4"
Suitable Application These Hoses Are Suitables, LPG, Water (but Not Potable Water) And Steam.
Temperature -20°C To 400°C
Type Gas Hose
