Part Number: 7661
TEL96 Ventilator - Brown/White
Free area 148 cm² (23 in²). Through wall length: 280 mm to 330 mm (11" to 13") telescopic. Size of internal vent: 270 mm x 194 mm. Air brick colour: Terracotta or brown/internal vent white. For appliances up to 36 kW Net - (40 kW Gross).
See More >
Product Specification
| Standards | BS 5440-2 |
| Colour | Brown |
| Dimensions | External Grille 140 mm x 218 mm , Internal Grille 194 mm x 270 mm |
| Free Area | 148 cm² |
| Free Area Size | 148 cm² |
| Internal Vent Size | 270 mm x 194 mm |
| Length | 280 to 330 mm |
| Size | 9" x 6" |
| Tube Diameter | 145 mm x 220 mm (9"x6") |
| Type | Two Brick Ventilator |
