UG G10P Diaphragm Gas Meter - 16m³/hr

£278.10 £231.75
£278.10 £231.75
More product options available

Part Number: 27292

Manufacturer's Part Number: G10P-NG

UG G10P Diaphragm Gas Meter - 16m³/hr

16 m³/hr diaphragm meter manufactured by a BS EN ISO 9001 company in Europe, certified under the European certification regime, and sealed. Check that this meter has the inlet/outlet dimension ‘A’ and thread size which meet your requirements because these may differ from the traditional ‘UK’ meter dimensions.
Meter reads in cubic metres.
Supplied with a pulse facility, approved to MID (04/22/EC) and BS EN 1359.
Metrology is in accordance with BS EN 1359 and MID.

No claim in respect of damage, internal or external, to a gas meter will be accepted unless such damage is notified in writing by the end of the working day following our customer’s receipt of the meter. We suggest that the internal mechanism is checked by passing air through the meter and noting that it registers.

See More >

Product Specification

Standards BS EN ISO 9001
Capacity 16 m³/h
Connection 1.1/4" BS 746
Display Mechanical
Material Steel
Max. Capacity 10 m³/hr at 0.5 mbar pressure loss
Max. Operating Pressure 500 mbar
Meter Code UG G10P
Meter Connection Size 1.1/4" BS 746
Meter Type Diaphragm
Pulse Rate 0.01 m³/pulse
Suitable Application Natural Gas & LPG
Test Point No
Type Commercial Meter
