Universal Electrofusion End Cap - 20mm

£3.70 £3.08
£3.70 £3.08
More product options available

Part Number: 23340

Manufacturer's Part Number: WA1202

Universal Electrofusion End Cap - 20mm

Black MDPE fitting with 4 mm dia. terminal pins for use with MDPE (PE80) pipe. Manufactured by a BS EN ISO 9001:2015 registered company. For Natural Gas, LPG and Water.

Please refer to the fitting's packaging for the most up to date pressure rating, fuse and cool times, and product approval.

Product Specification

Approved by WRAS, BSI & Kitemarked
Standards Gas - GIS/PL2-4 & BS EN 1555. Water - BS EN 12201-3.
Colour Black
Material MDPE
Operating Pressure Gas: MOP up to 5.5 bar. Water: MOP up to 16 bar.
Size 20 mm
Suitable Application For use with MDPE (PE 80) pipe carrying Natural Gas, LPG or Water.
Terminal Pin Size 4 mm
Type End Cap
