Part Number: 22290
VHU20 Ultrasonic Heat Meter Kit - DN20 3/4" BSP M
The VHU Ultrasonic heat meter has a dismountable LCD unit, M-Bus communications interface, sensor body with BSP threaded unions, washers and nuts, 1.5 m M-bus cable and two matched temperature sensors, for water-based systems with temperatures from 5 to 90°C.
Low energy consumption with up to 10 years battery life.
Low energy consumption with up to 10 years battery life.
Product Specification
| Brand | VHU |
| Standards | BS EN 1434-2/+A1 |
| Application | Heat Meter |
| Connection | BSP M |
| Flow Rate | 5 m³/h |
| Material | Plastic |
| Max. Operating Pressure | Allowable: 16 bar |
| Meter Dimensions | 130 mm x 83 mm x 94 mm |
| Nominal M3/H | 2.5 |
| Power Supply | Battery |
| Size | DN20, 3/4" |
| Temperature Range | 5°C to 90°C |
| Type | Heat Meter |
| Weight | 0.95 kg |
