Water Swing Check Valve - Brass 2" BSP

Name: Water Swing Check Valve - Brass 2" BSP
Brand: Unbranded
SKU: 7467
Price: 35.13 GBP
Availability: InStock

Water Swing Check Valve - Brass 2" BSP is a robust swing check valve designed for water or oil low-pressure systems. Featuring a durable brass construction with a metal seat and swing-type metal disc, it ensures reliable one-way flow control.

This valve can be installed in either horizontal positions or vertically for upward flow, providing versatile application options.

With a maximum operating pressure of 16 bar and temperature capacity up to 100°C, it is suitable for hot or cold water and low-pressure oil systems.

The BSP parallel female-to-female connections ensure a secure fit in compatible systems, and the brass construction ensures long-lasting durability.

The 2" Brass Water Swing Check Valve offers a dependable solution for controlling one-way flow in water or low-pressure oil systems, with flexible installation options and a durable brass design for enhanced reliability.

Alternative Options available.

Benefits

Reliable flow control for water or low-pressure oil systems
Maximum operating pressure of 16 bar
Suitable for both hot and cold water applications
Versatile installation in horizontal or vertical orientations
Maximum temperature of 100°C

BSP Explained

BES Ltd., British Standard Pipe Thread Identification Chart.

BSP – This is an abbreviation used for British Standard Pipe threads, and the size refers to the nominal bore (or internal diameter) of the steel pipe the thread was originally designed for, not the diameter of the actual thread. Please measure your maximum (or major) thread diameter in millimetres and use the chart below to identify the BSP size you need.

Further advice can be obtained from our Technical Team if you are still unsure.

BSP Size	Actual Diameter of Thread
1/8"	9.728 mm
1/4"	13.157 mm
3/8"	16.662 mm
1/2"	20.995 mm
3/4"	26.441 mm
1"	33.249 mm
1 1/4"	41.910 mm
1 1/2"	47.803 mm
2"	59.614 mm
2 1/2"	75.184 mm
3"	87.884 mm

The information above is provided for guidance only. The data shown represents extracts interpreted by us of the British Standards. If more clarification and accuracy is required, you should refer to the relevant British Standard.

Product Specification

Connection	BSP ParaIIel Female x Female
Fitting Type	Brass
Max. Operating Pressure	16 bar
Max. Temperature	100°C
Size	2"
Suitable Application	For hot or cold water, or oil low pressure systems. May be fitted horizontal, or vertical fixing for upward flow only.
Type	Swing Check Valve
