Y In-line Strainer Brass - 1.1/4" BSP PF

Name: Y In-line Strainer Brass - 1.1/4" BSP PF
Brand: Unbranded
SKU: 7539
Price: 22.48 GBP
Availability: InStock

The Y In-line Strainer Brass - 1.1/4" BSP PF is engineered to efficiently remove particles from fluid systems, featuring a robust brass body with a 0.50 mm (500-micron) stainless steel mesh for dependable filtration. Ideal for applications where ease of maintenance is essential, this strainer allows for cleaning the filter mesh without removing it from the pipeline.

Built to withstand demanding conditions, it operates effectively up to a maximum pressure of 20 bar and can handle temperatures as high as 110°C, making it suitable for various liquid filtration tasks.

The Y In-line Strainer Brass - 1.1/4" BSP PF offers reliable filtration with a durable brass body and stainless steel mesh that’s easy to clean. With a 1.1/4" BSP F x F connection, it’s designed to meet rigorous filtration needs up to 20 bar and 110°C, without removal from the pipeline.

PLEASE NOTE: Not for use with gas

Alternative Options available.

Benefits

Effective 500-micron stainless steel mesh for particle capture
Cleanable filter mesh without pipeline removal
Brass body for enhanced durability and corrosion resistance
Operates at up to 20 bar working pressure
Temperature range up to 110°C for demanding applications
1.1/4" BSP F x F connection for secure fitting

BSP Explained

BES Ltd., British Standard Pipe Thread Identification Chart.

BSP – This is an abbreviation used for British Standard Pipe threads, and the size refers to the nominal bore (or internal diameter) of the steel pipe the thread was originally designed for, not the diameter of the actual thread. Please measure your maximum (or major) thread diameter in millimetres and use the chart below to identify the BSP size you need.

Further advice can be obtained from our Technical Team if you are still unsure.

BSP Size	Actual Diameter of Thread
1/8"	9.728 mm
1/4"	13.157 mm
3/8"	16.662 mm
1/2"	20.995 mm
3/4"	26.441 mm
1"	33.249 mm
1 1/4"	41.910 mm
1 1/2"	47.803 mm
2"	59.614 mm
2 1/2"	75.184 mm
3"	87.884 mm

The information above is provided for guidance only. The data shown represents extracts interpreted by us of the British Standards. If more clarification and accuracy is required, you should refer to the relevant British Standard.

Product Specification

Connection	F x F BSP
Material	Brass
Max. Operating Pressure	Working: 20 bar
Max. Operating Temperature	110°C
Mesh Type	0.50 mm (500 micron)
Size	1.1/4"
Type	Y Inline Strainer
