Y In-line Strainer Brass - 2" BSP PF

Name: Y In-line Strainer Brass - 2" BSP PF
Brand: Unbranded
SKU: 7541
Price: 50.79 GBP
Availability: InStock

The Y In-line Strainer Brass - 2" BSP PF is designed for filtering out particles in liquid pipelines, offering efficient and effective filtration with easy maintenance. This product is equipped with a stainless steel mesh filter that can be cleaned without removing the strainer from the pipeline, ensuring minimal downtime and hassle.

The product features a robust brass construction for durability and resistance to corrosion. The 2" F x F BSP connections allow for straightforward installation in various plumbing systems.

The maximum operating pressure of 20 bar ensures reliable performance under demanding conditions. With a maximum operating temperature of 110°C, this strainer is suitable for a wide range of applications.

The mesh type has a fine 0.50 mm (500 micron) filtration capability to catch even the smallest particles.

The Y In-line Strainer offers effective filtration, durable brass construction, easy cleaning, high-pressure tolerance, and a fine mesh filter, making it ideal for maintaining fluid integrity in pipelines.

PLEASE NOTE: Not for use with gas

Alternative Options available.

Benefits

Durable brass material
Easy-to-clean mesh
High-pressure tolerance up to 20 bar
Maximum operating temperature of 110°C
0.50 mm (500 micron) mesh for fine filtration
Convenient 2" F x F BSP connections

BSP Explained

BES Ltd., British Standard Pipe Thread Identification Chart.

BSP – This is an abbreviation used for British Standard Pipe threads, and the size refers to the nominal bore (or internal diameter) of the steel pipe the thread was originally designed for, not the diameter of the actual thread. Please measure your maximum (or major) thread diameter in millimetres and use the chart below to identify the BSP size you need.

Further advice can be obtained from our Technical Team if you are still unsure.

BSP Size	Actual Diameter of Thread
1/8"	9.728 mm
1/4"	13.157 mm
3/8"	16.662 mm
1/2"	20.995 mm
3/4"	26.441 mm
1"	33.249 mm
1 1/4"	41.910 mm
1 1/2"	47.803 mm
2"	59.614 mm
2 1/2"	75.184 mm
3"	87.884 mm

The information above is provided for guidance only. The data shown represents extracts interpreted by us of the British Standards. If more clarification and accuracy is required, you should refer to the relevant British Standard.

Product Specification

Connection	F x F BSP
Material	Brass
Max. Operating Pressure	Working: 20 bar
Max. Operating Temperature	110°C
Mesh Type	0.50 mm (500 micron)
Size	2"
Type	Y Inline Strainer
