Caleffi Tempering Valve Safety Temperature Reduction - 1/2" BSP

Name: Caleffi Tempering Valve Safety Temperature Reduction - 1/2" BSP
SKU: 20756
Price: 90.84 GBP
Availability: InStock

Tempering Valve is a safety device designed to protect against scalding at outlets primarily used for personal hygiene. It is designed to control temperature in water mixing applications and safely reduce temperature to between 55 and 60°C. Can be used in systems where the water in the storage cylinder can reach temperatures significantly above 60°C, for example if heated by solar heating. Can be used with multiple outlets and frequently as part of a re-circulating domestic hot water system. Supplied with check valves and strainers.
Max. inlet pressure ratio: 2:1.
Min. temperature difference between hot water inlet and mixed outlet for best performance: 10°C.
Certified to BS EN 15092, Type 2 Adjustable temperature and WRAS approved.

BSP Explained

BES Ltd., British Standard Pipe Thread Identification Chart.

BSP – This is an abbreviation used for British Standard Pipe threads, and the size refers to the nominal bore (or internal diameter) of the steel pipe the thread was originally designed for, not the diameter of the actual thread. Please measure your maximum (or major) thread diameter in millimetres and use the chart below to identify the BSP size you need.

Further advice can be obtained from our Technical Team if you are still unsure.

BSP Size	Actual Diameter of Thread
1/8"	9.728 mm
1/4"	13.157 mm
3/8"	16.662 mm
1/2"	20.995 mm
3/4"	26.441 mm
1"	33.249 mm
1 1/4"	41.910 mm
1 1/2"	47.803 mm
2"	59.614 mm
2 1/2"	75.184 mm
3"	87.884 mm

The information above is provided for guidance only. The data shown represents extracts interpreted by us of the British Standards. If more clarification and accuracy is required, you should refer to the relevant British Standard.

Product Specification

Brand	Caleffi
Approved by	WRAS
Standards	BS EN 15092
Accuracy	±2°C
Adjustment Range	45 to 65°C
Connection	BSP
Flow Rate	Min.: 4 l/min
Inlet Temperature	Max: 90°C
Material	DZR Chrome Plated
Pressure	10 bar static, 5 bar dynamic
Size	1/2"
Type	Tempering Valve
WRAS Approved	Approval Number: 2205038
