Part Number: 17072
Manufacturer's Part Number: 503110304
The DAB Novabox will collect and lift waste water from a bath, shower or washing machine located in a basement or below the level of the sewage network. Equipped with a Nova 300 electropump with 5 metres of cable, a 30 litre technopolymer container and outlet check valve. It does not pump solids or fibrous substances.
Supply voltage : 220-240 V, 50 Hz.
Max. flow rate : 7.5 m3/h.
Max. pump head : 6.9 m.
Liquid temp. : 50°C (90°C max. time 3 min).
Pump motor protection level : IP68.
Dimensions : H 360 x W 407 x D 309 mm.
Weight : 9 kg.
Supply voltage : 220-240 V, 50 Hz.
Max. flow rate : 7.5 m3/h.
Max. pump head : 6.9 m.
Liquid temp. : 50°C (90°C max. time 3 min).
Pump motor protection level : IP68.
Dimensions : H 360 x W 407 x D 309 mm.
Weight : 9 kg.
Product Specification
Brand | DAB |
Sub Brand | Novabox |
Cable Length | 5 m |
Capacity | 30 litres |
Dimensions | 360 mm x 407 mm x 309 mm |
Flow Rate | 7.5 m3/h |
Max. Head | Pump: 6.9 m |
Motor Protection | IP68 |
Supply Voltage | 220-240V, 50 Hz |
Temperature | Liquid: 50°C, (90°C max. time 3 min) |
Type | Pump Unit |
Weight | 9 kg |
