Part Number: 22299
Manufacturer's Part Number: UUCSR485MCOKIT
Clesse LPG Manual Changeover Kit with CSR OPSO
Clesse CSR485 manual changeover (MCO) regulator fitted with Consumer Safety Reset (CSR) OPSO system offering enhanced protection and visible indication of activation, easily resettable by the end user.
Kit comprises : one manual changeover valve, one CSR485 MCO regulator, two 20" pigtails with high pressure hose to BS 3212 Type 2 or BS EN 16436-1 Class 3, assembled to BS 3212 and POL connectors incorporating excess flow and non-return valves, mounting bracket, shut-off valve and test point.
Manufactured to EN 16129.
|Standards||BS 3212 Type 2|
|Capacity||4 kg/h (187,500 Btu/h)|
|Inlet Pressure||Max: 20 bar|
|Kit Contents||Kit comprises one manual changeover valve, one regulator, and two 20" pigtails with high pressure black hose to BS 3212:Type 2 and POL connectors incorporating excess flow and non-return valves, mounting bracket and shut-off valve.|
|Outlet Connection||1/2" BSP F|
|Outlet Pressure||37 mbar|
|Pressure Relief Valve||75 mbar|
|Type||Manual Changeover Kit|
