Part Number: 9619

Mini Gas Ball Valve - 6mm Compression

Name: Mini Gas Ball Valve - 6mm Compression
Brand: Unbranded
SKU: 9619
Price: 6.52 GBP
Availability: InStock

Lever handle mini gas ball valve to BS EN 331.

Manufactured and tested to BS EN 331 by a BS EN ISO 9001 registered company. Compact plated brass ball valve with yellow coded operation lever. The handle may easily be removed to expose a screwdriver slot and spanner flats for alternative operation.
For Natural Gas, LPG, water, oils and compressed air.

Product Specification

Approved by	BS EN ISO 9001 & BS EN 331
Application	For Natural Gas, LPG, water, oils and compressed air.
Connection	Compression
Finish	Plated
Full Bore	No
Handle	Lever
Handle Colour	Yellow
Lockable	No
Material	Brass
Max. Operating Pressure	20 bar
Max. Operating Temperature	80°C
Size	6 mm
Temperature Range	-20 to 80°C
Type	Lever Valve
