Part Number: 8211

Gas Meter Bracket for U6,E6 & G4 Meters 3/4" Inlet

A meter bracket is designed to suspend a gas meter, using the two male threaded bosses on the top of the meter. Specially designed meter unions and adaptors with grooves in them (P/Ns 0980, 0981, 0982, 20353 or 0217) are slid into the slots in the meter bracket and the meter is then attached to these. A security washer and shear bolt should be used to prevent unauthorised removal of the meter union or adaptor from the bracket.
The meter brackets may be fixed to a wall, or to the floor-mounted bracket (P/N 6229).

Inlet and outlet accept P/Ns 0981, 0982, 20353 or 0217 (giving 22 mm capillary male, 3/4" BSP taper male, 28 mm male/22 mm female capillary or 1" BS 746 male threads respectively). The above brackets (P/Ns 8210 and 8211) will accept U6, G4 and E6.G130 meters - P/Ns 19957, 12845 and 21122.

Product Specification

Adaptor Type Bracket
Finish Passivated
Material Steel
Suitable Application Bracket For Fixing Meter To The Wall For G4 U6 E6 G130 Meters With 152.4 Mm Connection Centres
Type Meter Bracket
