Part Number: 23990
Manufacturer's Part Number: MW25CP
Pulsed Cold Water Meter - 1"
The Pulsed Cold Water Meter - 1" is designed for monitoring cold water consumption, making it ideal for integration with energy monitoring systems. Featuring a 25 mm nominal bore and a 1" BSP TM thread, this meter ensures precise water consumption tracking.
Constructed from durable cast copper alloy, the meter uses multi-jet and vane wheel operation for accurate measurement.
It is equipped with an inductive interface and an electronic pulse emitter module, which is compatible with Mbus modules and comes with a 1.5 m lead.
The meter is approved according to MID standards up to R100-H and R50-VH, ensuring it meets rigorous industry standards.
With a maximum flow rate of 6.3 m³/h and a maximum operating pressure of 16 bar, the meter is built for reliable performance.
It is WRAS approved and operates at a maximum cold water temperature of 50°C. The pulse measurement is set at 1 pulse per 10 litres, ensuring accurate data transmission.
The Pulsed Cold Water Meter - 1" offers precise water consumption monitoring with its copper alloy body and inductive pulse emitter. It is ideal for energy monitoring systems and meets MID and WRAS standards for reliable performance.
Alternative Options available.
Benefits
- 25 mm nominal bore with 1" BSP TM thread for precise measurement
- Constructed from durable cast copper alloy for longevity
- Multi-jet and vane wheel operation for accurate readings
- Inductive interface and electronic pulse emitter with Mbus compatibility
- Approved to MID standards up to R100-H and R50-VH
- Maximum flow rate of 6.3 m³/h and pressure rating of 16 bar
- 1 pulse per 10 litres for precise monitoring
- WRAS approved for safety and compliance
- Maximum cold water temperature of 50°C for versatility in usage
Specification
Approved by | WRAS |
Application | Monitoring cold water consumption. |
Bore | 25 mm |
Cold Water Meter Max Temp | 50° C |
Connection | BSP TM |
Material | Copper Alloy |
Max. M3/H | 6.3 |
Max. Operating Pressure | 16 bar |
Measurement | 1 pulse per 10 litres |
Nominal Bore | 25 mm |
Pulsed Facility | Yes |
Size | 1" |
Type | Cold Water Meter |
