Part Number: 23643
Manufacturer's Part Number: METCAPG4U6
Meter Cap BS 746 - 1" F Black Plastic
Used to temporarily cap a 1" BS 746 meter connection to prevent dirt, dust or insect ingress.
Must not be used for sealing under working or test pressures.
BES Ltd Gas Meter Union – BS 746 Thread Conversion Chart
BS 746 is the specification that applies specifically to Gas Meter Installations. The size name refers to the internal bore size of the meter unions and the ECV (main gas cock), not the thread diameter. To ensure you order the correct fittings, please measure the thread diameter of the male thread on your meter or ECV in millimetres, and then use the chart below to identify the BS 746 size.
BSP 746 Name | Actual Thread Size in mm | Nut Size (Flat to Flat) in mm |
---|---|---|
3/4" | 29 mm | 35 mm |
1" | 37 mm | 42 mm |
1 1/4" | 44 mm | 53 mm |
1 1/2" | 57 mm | 66 mm |
2" | 76 mm | 80 mm |
Product Specification
Adaptor Type | Cap |
Colour | Black |
Connection | BS 746 |
Material | Plastic |
Size | 1" |
Suitable Application | Temporary cap for a BS 746 meter connection. |
Thread Type | BS 746 F |
Type | Meter Cap |
Type Of Connector | Female |
